ALPINE 12 CHANNEL SOUND PROCESSOR W/ BUILT-IN 8 CH AMP
Description
High-performance of DSP, fast for running speed, the transmit and receive clock is up to 50MHz. Also, Highly configured audio CODEC chip PCM3168, with 192kHz
Add the mixing function
• Music & navigation sound mixing • Can arbitrarily adjust the volume ratio of main/sub audio source
Optimize UI style
Full-frequency mode is added, and each channel can be set to full-frequency mode, which solves the problem that channels cannot be distributed in projects such as audition rooms and RVs to reduce the setting time.
Add dedicated interface for delay
Split-screen display, adding delay group, more convenient operation!
Optimize the wire control to improve operation
• Total volume adjustment • Bass volume adjustment • Sound source switching • Auxiliary sound source switching • EQ preset switching
Specifications:
• Frequency Response: 20Hz - 20KHz
• Inputs:
- 6 high-level signal inputs
- 6-channel RCA signal
- Optical fiber/ Coaxial digital signal input
- Bluetooth signal input
• Outputs:
- 8 x 25W (Rated power)
- 12-channel RCA output
• Sounding & Tuning:
- 2.0 multichannel surround
- 31 Bands parametric EQ
- Hi-pass / Low-pass / Bandpass Crossover
- Time delay up to 20 ms per channel
- Input/output frequency summing
- Music & navigation sound mixing
• Dimensions:
- 210 x 190 x 45 mm
