110mm Double DIN cradle fitting frame with black plastic trim ring surround
Used to surround a double DIN head unit so it can be mounted and locked into place within the vehicles dash.
Supplied with:
- Double DIN fitting frame: 180mm across x 110mm high x 100mm deep
- 1 x Black plastic trim ring surround for finishing the installation neatly and professionally
- Left and right plates that screw to the head unit and then lock into the double DIN fitting frame
- 2 x Brackets used for clamping the plates. These brackets allow for the head unit to be moved backwards and forwards in the cradle to move it into a position where it is flush with the dash of the vehicle.
- Keys for easy removal of the head unit from the double DIN fitting frame
- 4 x ISO screws for fastening the left and right plates to the sides of the head unit
- 2 x Foam pads
Cradle Size:
- Internal Dimensions: 180mm W x 100mm H
- External Dimensions: 182mm W x 103mm H
- Mounting Cage Dimensions: 186mm W x 117mm H
Trim Ring Size:
- Internal Dimensions: 174mm x 97mm H
- External Dimensions: 188mm W x 118mm H
|
